Home Products TFT LCD Standard TFT Color Display
TFT Color Display, TFT Color LCD, Color LCD Display Module, Color LCD Module, Standard LCD Display

Standard TFT LCD Display, TFT Color LCD Display Module

Winstar TFT LCD Module Manufacturer

Winstar standard TFT-LCD display modules are available in various sizes from 1.77" to 8" TFT LCD, such as 2.4" TFT display, 2.8" TFT display , 3.5" TFT display, 4.3" TFT display5 inch TFT display, 7" LCD display.  These TFT LCD modules are including options of TFT panel, TFT LCM with controller board, industry standard mono TFT LCM, TFT color display, and wide operating temperatures of -20°C to +70°C or -30°C to +80°C.

Winstar TFT displays are available in various graphic display resolutions including QVGA (320 x 240), WQVGA (480x272), VGA (640x480), WVGA (800x480), 640x320, 1024x600, XGA (1024x768) and WXGA(1280x800).  Many of Winstar TFT display modules have more than one interface available including MCU, RGB, TTL and LVDS as well as two touch panels optional in resistive and capacitive technology.

The list below is our standard offering. However, Winstar Displays has many more customized solution and special sizes available as options. Please contact us online for more information.

In this catalogue you can find ST7735 TFT display, Micro TFT display, capacitive touchscreen display...etc.

Filter Results

Filter Results

√ Select Display Format Picture Model No. Size
(inch)
Outline Dimension
(mm)
Viewing Area
(mm)
Active Area
(mm)
View Direction Interface IC Control-Board Brightness
(cd/m²)
Recommended Touch Screen Detect Points
(Finger)
Temperature
(°C)
High Resolution
128×160
TFT ST7735, ST7735 Display,1.77 TFT LCD - WF18FTLAADNN0
WF18FTLAADNN0 1.77 34×45.83 31.83×41.42 28.03×35.04 6H SPI,MCU ST7735S No 500 ★★ No -20~70
128×160
O-Filme 1.77-inch Color TFT LCD Display (128x160) - WF18FTZAADNN0
WF18FTZAADNN0 1.77 34×45.83 31.83×41.42 28.03×35.04 6H SPI,MCU ST7735S No 400 No -20~70
128×160
Micro TFT Display, LCD Display Module - WF18GTLAADNN0
WF18GTLAADNN0 1.77 34×45.83 31.83×41.42 28.03×35.04 6H SPI ST7735S No 500 ★★★ No -20~70
128×160
1.77
WF18HSLAADNN0 1.77 34×45.83 31.83×41.42 28.03×35.04 6H SPI ST7735S No 900 ★★★ No -20~70
240×320
2.4 inch TFT LCD Display, 2.4 TFT LCD Module, Winstar TFT 2.4
WF24HTLAJDNN0 2.4 42.72×60.26 37.72×49.96 36.72×48.96 6H MCU ILI9341 No 500 ★★★ No -20~70
240×320
2.4 TFT SPI 240x320, 2.4 TFT 240x320, 240x320 TFT LCD - WF24MTLAJDNN0
WF24MTLAJDNN0 2.4 42.72×60.26 37.72×49.96 36.72×48.96 6H SPI ST7789V No 500 No -20~70
240×320
SPI TFT Display, SPI TFT LCD, SPI LCD Display, SPI Display Module - WF24MTLAJDNT0
WF24MTLAJDNT0 2.4 42.72×60.26 38.72×53.96 36.72×48.96 6H SPI ST7789V No 350 RTP -20~70
240×320
2.8-inch 240x320 ILI9341 TFT Display, ILI9341 LCD, ILI9341 TFT - WF28ETLAJDNN0
WF28ETLAJDNN0 2.8 50×69.2 44.2×58.6 43.2×57.6 6H MCU ILI9341 No 500 ★★★ No -20~70
240×320
2.8inch 240x320 TFT LCD Display with ILI9341 IC - WF28ETLAJDNF0
WF28ETLAJDNF0 2.8 50×69.2 44.2×58.6 43.2×57.6 6H MCU ILI9341 No 400 PCAP 1 -20~70
240×320
2.8 inch TFT LCD, 2.8 TFT LCD Module, 2.8 TFT Display - WF28ETLAJDNT0
WF28ETLAJDNT0 2.8 50×69.2 44.8×63.1 43.2×57.6 6H MCU ILI9341 No 350 ★★★ RTP -20~70
240×320
2.8
WF28KTLAJDNT0 2.8 50×69.2 44.8×63.1 43.2×57.6 6H SPI ST7789V No 350 RTP -20~70
240×320
3.2 inch Portrait 240x320 TFT LCD Module - WF32DTLAJDNN0
WF32DTLAJDNN0 3.2 55.04×77.6 49.6×65.8 48.6×64.8 6H 8080,SPI,MCU ILI9341 No 500 ★★ No -20~70
240×320
3.2 TFT LCD, 3.2 TFT LCD Module, 3.2 LCD Display - WF32DTLAJDNT0
WF32DTLAJDNT0 3.2 55.04×77.6 49.6×65.8 48.6×64.8 6H 8080,SPI,MCU ILI9341 No 350 ★★ RTP -20~70
320×240
3.5 TFT, 3.5 inch TFT LCD Screen Display, 3.5 inch LCD Display, Display 3.5 - WF35LTIACDNN0
WF35LTIACDNN0 3.5 76.9×63.9 73.1×55.5 70.08×52.56 12H RGB HX8238 No 420 ★★★ No -20~70
320×240
3.5 inch Color TFT LCD Module with Resistive Touch Panel - WF35LTIACDNT0
WF35LTIACDNT0 3.5 76.9×63.9 72.1×54.6 70.08×52.56 12H RGB HX8238 No 300 ★★★ RTP -20~70

Showing 1 to 15 of 55 (4 Pages)
