Wide Temperature TFT LCD, LCD Temperature Display, Active Matrix TFT Colour LCD Display, TFT Active Matrix

TFT LCD Wide Temperature Display, Active Matrix TFT Colour LCD Display

Active Matrix TFT Colour LCD Display is becoming more pervasive for indoor or outdoor applications, especially the demand in wide temperature TFT LCD is growing in many fields. Winstar Display offers a full range of wide temperature TFT LCD modules; available in various sizes from 7" to 10.4". These TFT modules can be operating at Wide Temperature Range from -30℃ to 80℃ or up to 85℃.
#Active TFT Display #TFT Active Matrix # Wide Temperature LCD

Display Format	Model No.	Size (inch)	Outline Dimension (mm)	Viewing Area (mm)	Active Area (mm)	View Direction	Interface	IC	Control-Board	Power Board	Brightness (cd/m²)	Recommended	Touch Screen	Detect Points (Finger)	Temperature (°C)
320×240	WF35XTWACDNG0	3.5	76.84×63.84	71×53.51	70.08×52.56	IPS	RGB	ST7272A	No	No	400	★★★	PCAP	5	-30~85
320×240	WF35XTWACDNN0	3.5	76.84×63.84	73.1×55.5	70.08×52.56	IPS	RGB	ST7272A	No	No	500	★★★	No		-30~85
320×240	WF35YTWACDNNB	3.5	76.84×63.84	73.1×55.5	70.08×52.56	IPS	RGB	ST7272A	No	No	500	★★	No		-30~85
480×272	WF43WTWAESNN0	4.3	105.5×67.2	98.16×56.856	95.04×53.856	IPS	QSPI	NV3041A-01	No	No	500	★★★	No		-30~80
480×272	WF43WSWAESNN0	4.3	105.5×67.2	98.16×56.856	95.04×53.856	IPS	QSPI	NV3041A-01	No	No	1000	★★★	No		-30~80
800×480	WF70B6SWAGLNN0	7	169.8×109.7	154.9×93.8	152.4×91.44	IPS	LVDS	HX8249-A+HX8678-C	No	No	1100	★	No		-30~80
800×480	WF70B8SWAGDNT0	7	165.8×106.61	154.4×93.4	152.4×91.44	IPS	RGB	HX8249-A+HX8678-C	No	No	700	★	RTP		-30~80
800×480	WF70B8SWAGDNB0	7	165.8×106.61	153.4×92.4	152.4×91.44	IPS	RGB	HX8249-A+HX8678-C	No	No	800	★	PCAP	5	-30~80
1024×600	WF70D5TWAHLNN0	7	169.9×103.4	157×88.92	154.2144×85.92	IPS	LVDS	JD9165BA	No	No	600	★★★	No		-30~85
1024×600	WF70D5SWAHLNG0	7	169.9×103.4	155.22×87.19	154.2144×85.92	IPS	LVDS	JD9165BA	No	No	1000	★★	PCAP	5	-30~85
1024×600	WF70D5SWAHLNGA	7	202×135.5	155.22×86.92	154.2144×85.92	IPS	LVDS	JD9165BA	No	No	1000	★★★	PCAP	5	-30~85
1024×600	WF70D5SWAHMNN0	7	169.9×103.4	157×88.92	154.2144×85.92	IPS	MIPI DSI	JD9165BA	No	No	1300	★★★	No		-30~85
1024×768	WF0840ATWAMLNN0	8.4	199.5×149	174.9×132.2	170.8032×128.1024	IPS	LVDS	ST5821AH+ST5084AA	No	No	500	★	No		-30~80
1024×768	WF0840ATWAMLNB0	8.4	199.5×149	172.21×129.53	170.8032×128.1024	IPS	LVDS	ST5821AH+ST5084AA	No	No	400	★	PCAP	2	-30~80
1024×768	WF0840ASWAMLNN0	8.4	199.5×149	174.9×132.2	170.8032×128.1024	IPS	LVDS	ST5821AH+ST5084AA	No	No	1000	★	No		-30~80

Showing 1 to 15 of 22 (2 Pages)
