TFT Display Panel with TFT LCD Controller Boards

TFT Display Panel with TFT LCD Controller Board

WINSTAR Display as a TFT LCD Display manufacturer has devoted itself to develop innovative TFT-LCD display new series including Winstar Q Series and P Series.   Winstar Display TFT Q Series Family (TFT Panels with SSD1963 TFT LCD Controller Board) is featuring an important key element of having an integrated 36-pinout connecter on the SSD1963 controller board.  The Q Series TFT modules are derivative products from Winstar standard TFT modules which unified the pin assignment into 36 pins on board.  The TFT Q Series is optional in 8 bit or 16 bit and already defined pin no. 33 ~ 36 as backlight supply; therefore, the customers no need to design extra backlight circuit.  Winstar Q series is support with Solomon SSD1963 Which has the traditional inputs and drive TFT by VESA signal. The customers don’t need to design T-COM circuit on board.  Winstar have integrated all functions including TFT connection, backlight driver, and touch panel (capacitive touch screen / resistive touch screen) into one controller board.

The modules of Winstar TFT P Series (TFT Panels with RA8875 Controller Board) are similar to TFT Q series which are also featured with an integrated 36-pinout connector on board. The P Series TFT modules are derivative products from the Winstar standard TFT modules which unified the pin assignment into 36 pins on a RA8875 controller board.  The P Series is support with 8 bit or 16 bit options and also already defined pin no. 33 ~ 36 as backlight supply; therefore, the customers no need to design extra backlight circuit.  Winstar TFT P series supports many import function including Chinese character display, backlight brightness adjustment, Flash Memory and touch panel driver, etc.

Filter Results

Filter Results

√ Select Display Format Picture Model No. Size
(inch)
Outline Dimension
(mm)
Viewing Area
(mm)
Active Area
(mm)
View Direction Interface IC Control-Board Power Board Brightness
(cd/m²)
Recommended Touch Screen Detect Points
(Finger)
Temperature
(°C)
High Resolution
480×272
4.3 inch IPS 480x272 RTP with Controller Board, Frame - WF43WTYBEDAT0
WF43WTYBEDAT0 4.3 106.7×83.98 98.16×56.856 95.04×53.86 IPS MCU SSD1963 Yes 350 RTP -20~70
480×272
4.3 inch IPS 480x272 TFT LCD with Controller Board - WF43WTYFEDBN0
WF43WTYFEDBN0 4.3 105.5×67.2 98.16×56.856 95.04×53.856 IPS MCU SSD1963 Yes 500 No -20~70
1280×800
10 inch IPS TFT LCD 1280x800 with PCAP Touch - WF101KTYJPLNG0
WF101KTYJPLNG0 10.1 257.96×168.6 218×137 216.96×135.6 IPS LVDS EK79202B1 No Yes 300 PCAP 5 -20~70
1280×800
10.1 inch High Brightness IPS TFT 1280x800 with PCAP - WF101LSYJPLNG0
WF101LSYJPLNG0 10.1 257.96×168.6 218×137 216.96×135.6 IPS LVDS EK79202B1 No Yes 900 PCAP 5 -20~70
1024×600
10 inch High Brightness IPS TFT Display with PCAP - WF101JSYJHLNB0
WF101JSYJHLNB0 10.1 235×143 223.72×126.28 222.72×125.28 IPS LVDS EK79007AD3+EK73217BCGA No Yes 900 PCAP 5 -20~70
320×240
3.5 TFT Display Panel with TFT LCD Controller Board - WF35QTIBCDBN0
WF35QTIBCDBN0 3.5 93.5×63.44 73.1×55.5 70.08×52.56 12H MCU SSD1963 Yes 420 ★★★ No -20~70
320×240
Resistive Touch Screen TFT 3.5, LCD Controller Board - WF35QTIBCDBT0
WF35QTIBCDBT0 3.5 93.5×63.44 73.1×55.5 70.08×52.56 12H MCU SSD1963 Yes 300 ★★★ RTP -20~70
320×240
3.5 PCAP Touchscreen TFT with LCD Controller Board - WF35QTIBCDBG0
WF35QTIBCDBG0 3.5 93.5×63.44 71×53.51 70.08×52.56 12H MCU SSD1963 Yes 340 ★★★ PCAP 5 -20~70
480×272
4.3
WF43QTIBEDBND 4.3 106.7×69.6 98.8×57.5 95.04×53.856 12H MCU SSD1963 Yes 500 ★★★ No -20~70
480×272
Tesistive Touch Panel TFT with LCD Controller Board 4.3 - WF43QTIBEDBTD
WF43QTIBEDBTD 4.3 106.7×83.98 98.7×57.5 95.04×53.856 12H MCU SSD1963 Yes 350 ★★★ RTP -20~70
480×272
4.3 PCAP TFT Panel with LCD Controller Board - WF43QTIBEDBGF
WF43QTIBEDBGF 4.3 106.7×83.98 96.24×54.66 95.04×53.856 12H MCU SSD1963 Yes 400 ★★★ PCAP 5 -20~70
800×480
5 inch TFT Panel with LCD Controller Board - WF50FTYFGDBGA
WF50FTYFGDBGA 5 120.7×75.8 109×65.6 108×64.8 IPS MCU SSD1963 Yes 400 ★★★ PCAP -20~70
480×128
5.2 inch 480x128 Bar Type TFT LCD - WF52CTLBSDBN0
WF52CTLBSDBN0 5.2 180×65 133×39 127.152×33.9072 O-TFT MCU MR6566 Yes Yes 500 No -20~70
320×240
5.7 TFT Display Panel with Controller Board - WF57A2TIBCDBN0
WF57A2TIBCDBN0 5.7 141.12×101.55 117.9×89.1 115.2×86.4 12H MCU SSD1963 Yes 900 ★★★ No -20~70
320×240
5.7 TFT Panel (RTP) with LCD Controller Board - WF57A2TIBCDBT0
WF57A2TIBCDBT0 5.7 141.12×101.55 118.2×89.4 115.2×86.4 12H MCU SSD1963 Yes 600 ★★★ RTP -20~70

Showing 1 to 15 of 35 (3 Pages)
