IPS TFT LCD, TFT IPS, TFT LCD IPS, IPS LCD Panel, IPS LCD Display

IPS TFT LCD, TFT IPS, IPS LCD Panel, IPS LCD Display

Winstar TFT LCD product portfolio come with IPS (In-Plane Switching) TFT LCD display modules, we offer a full range of modules; available sizes are including mini IPS TFT 0.96", 2.4", 3.5", 3.97", 5", 7", 8.8", 9", 10.1" , 12.1" and 12.3 inch, to deliver better performance in a range of demanding situations, we also offer higher brightness version (750~1100 cd/m2) as options for some models, such as WF35W, WF50D, WF50E, WF70A4 and WF12.3B. We offer resistive touchscreen (RTP) or capacitive touchscreen (PCAP) for optional as well. These wider view TFT IPS LCD display can be operating at temperature range from -20℃ to +70℃ or up to +85℃; and storage temperatures from -30℃ to +85℃ or +90℃.  The IPS TFT LCD Panel is becoming very popular because of featuring super wider viewing angle. It also improves the aperture ratio to produce higher brightness with improved color reproducibility.

In this IPS catalogue you can find MINI TFT LCD display, MIPI interface display, IPS touch display, LVDS TFT display, 1280x800 display, 1024x768 display, 1920x720 display...etc.

Filter Results

Filter Results

√ Select Display Format Picture Model No. Size
(inch)
Outline Dimension
(mm)
Viewing Area
(mm)
Active Area
(mm)
View Direction Interface IC Part No. Control-Board Brightness
(cd/m²)
Recommended Touch Screen Detect Points
(Finger)
Temperature
(°C)
80×160
Mini LCD Display, Mini IPS, 0.96 TFT, Mini TFT LCD, Mini TFT (80x160) - WF0096ATYAA3DNN0
WF0096ATYAA3DNN0 0.96 13.5×27.95 11.4×22.27 10.8×21.696 IPS SPI ST7735S No 500 ★★ No -20~70
80×160
0.96 inch 80x160 TFT LCD Display with Projected Capacitive Touch Panel - WF0096ATYAA3DNF10
WF0096ATYAA3DNF10 0.96 18.7×31.9 10.8×21.696 10.8×21.696 IPS SPI ST7735S No 400 PCAP 1 -20~70
240×320
2.4 IPS Color TFT Module
WF24LTYAJDNN0 2.4 42.72×60.26 38.72×51.16 36.72×48.96 IPS SPI,MCU ILI9341 No 500 ★★ No -20~70
240×320
2.8 inch 240x320 TFT IPS LCD Display
WF28JTYAJDNN0 2.8 50.5×69.7 44.2×58.6 43.2×57.6 IPS SPI,MCU ILI9341 No 500 ★★ No -20~70
240×320
2.8 inch 240x320 Sunlight Readable TFT IPS LCD - WF28JSYAJDNN0
WF28JSYAJDNN0 2.8 50.5×69.7 44.2×58.6 43.2×57.6 IPS SPI,MCU ILI9341 No 1000 ★★ No -20~70
320×240
3.5
WF35XTYACDNN0 3.5 76.84×63.84 73.1×55.5 70.08×52.56 IPS RGB ST7272A No 500 ★★★ No -20~70
320×240
3.5
WF35XSYACDNN0 3.5 76.84×63.84 73.1×55.5 70.08×52.56 IPS RGB ST7272A No 1000 ★★★ No -20~70
320×480
3.5 TFT IPS LCD Display - WF35UTYAIDNN0
WF35UTYAIDNN0 3.5 54.5×83 49.76×74.24 48.96×73.44 IPS SPI,MCU,RGB ILI9488 No 600 No -20~70
480×800
3.97 inch IPS, MIPI Interface TFT LCD Module 480x800
WF40CTYAQMNN0 3.97 57.14×96.85 52.84×87.40 51.84×86.4 IPS MIPI DSI ST7701S No 600 No -20~70
480×480
480x480 TFT LCD Display Module 4
WF40ETWAA6MNN0 4 78.8×82.95 73.06×71.38 71.856×70.176 IPS MIPI DSI ST7701S No 500 No -30~80
480×480
4 inch 480x480 Wide Temperature IPS TFT Display with ST7701S driver IC  - WF40ETWAA6DNN0
WF40ETWAA6DNN0 4 78.8×82.95 73.06×71.38 71.856×70.176 IPS RGB ST7701S No 500 No -30~80
480×480
4 TFT LCD, TFT LCD 4, TFT 4, 4 TFT Display, 4 TFT, 4 inch TFT Display, 4 LCD Display - WF40ESWAA6MNN0
WF40ESWAA6MNN0 4 78.8×82.95 73.06×71.38 71.856×70.176 IPS MIPI DSI ST7701S No 1000 No -30~80
480×480
4 inch 480x480 High Brightness TFT Module with Resistive Touch Panel - WF40ESWAA6MNT0
WF40ESWAA6MNT0 4 78.8×82.95 73.06×71.38 71.856×70.176 IPS MIPI DSI ST7701S No 700 RTP -30~80
480×272
4.3
WF43WSWAEDNN0 4.3 105.5×67.2 98.9×57.7 95.04×53.856 IPS RGB SC7283 No 1000 ★★★ No -30~80
480×272
4.3 IPS TFT LCD Display Module 480x272
WF43WTWAEDNN0 4.3 105.5×67.2 98.16×56.856 95.04×53.856 IPS RGB SC7283 No 500 ★★★ No -30~80

Showing 1 to 15 of 50 (4 Pages)
