New Products

Filter Results

Filter Results

√ Select Display Format Picture Model No. Structure Size
(inch)
Outline Dimension
(mm)
Viewing Area
(mm)
Active Area
(mm)
View Direction Dot Size
(mm)
Interface Interface (System) IC Part No. Control-Board Brightness
(cd/m²)
Recommended Grayscale Touch Screen Detect Points
(Finger)
Temperature
(°C)
800×480
WL0F00050000FGAAASA00 --   68.4×122.7           CAN               -20~70
480×480
WF40ETWAA6MNN0   4 78.8×82.95 73.06×71.38 71.856×70.176 IPS   MIPI DSI   ST7701S No 500   No -30~80
480×480
WF40ESWAA6MNN0   4 78.8×82.95 73.06×71.38 71.856×70.176 IPS   MIPI DSI   ST7701S No 1000   No -30~80
800×480
WF50FTWAGLNN0   5 120.7×75.8 110.7×67.4 108×64.8 IPS   LVDS   ST7262 No 500 ★★★   No -30~80
800×480
WF70A9TWAGDNN0   7 165.8×106.61 154.9×93.8 152.4×91.44 IPS   RGB   HX8249-A+HX8678-C No 500 ★★★   No -30~80
800×480
WF70A9SWAGDNN0   7 165.8×106.61 154.9×93.8 152.4×91.44 IPS   RGB   HX8249-A+HX8678-C No 1000 ★★★   No -30~80
1024×600
WF70A8SYAHLNT0   7 169.9×103.4 156.6×89.1 154.2144×85.92 IPS   LVDS   ST5021+ST5651 No 800   RTP -20~70
1024×600
WF70A8SYAHLNG0   7 169.9×103.4 156.08×87.92 154.2144×85.92 IPS   LVDS   ST5021+ST5651 No 850   PCAP 5 -20~70
1024×600
WF101JSYAHLNN0   10.1 235×143 226×128.5 222.72×125.28 IPS   LVDS   EK79001HN+EK73215BCGA No 1100   No -20~70
1024×600
WF101JTYAHLNN0   10.1 235×143 226×128.5 222.72×125.28 IPS   LVDS   EK79001HN+EK73215BCGA No 500   No -20~70
1024×600
WF70MTABHLRN0   7 166.2×101.2 156.08×87.92 154.08×85.92 12H   SPI,UART   STM32 Yes 350   PCAP 1 -20~70
800×480
WF50FSYFGDHGV   5 120.7×75.8 109×65.1 108×64.8 IPS   HDMI (CN)   TFP401 Yes 750 ★★   PCAP 1,2,option -20~70
800×480
WF70B2SIAGDNG0   7 165×100 156.68×88.52 154.08×85.92 12H   RGB   HX8264-E+HX8664-B No 700 ★★★   PCAP 5 -20~70
128×64
WEO012864A-CTP COG 1.54 43.04×28.22 37.05×19.52 35.05×17.51   0.249×0.249 6800,8080,SPI,I2C   SSD1309       No PCAP 1
128×64
WEO012864Q-CTP COG 2.7 73×41.16 63.41×32.69 61.41×30.69   0.45×0.45 6800,8080,SPI,I2C   SSD1309       No PCAP 1
128×128
WEO128128D-CTP COG 1.18 Ø50.5 Ø31 Ø30   0.21×0.21 SPI,I2C   SSD1327       Support PCAP 1
256×64
WEO025664D-CTP COG 3.55 100.4×36.1 88.52×22.28 87.52×21.28   0.312×0.303 6800,8080,SPI   SSD1322       Support PCAP 1
128×64
WEA012864MX COG+PCB 0.96 27.3×27.3 23.744×13.204 21.744×11.204   0.148×0.148 I2C   SSD1306       No No
256×64
WEX025664B-CTP COF 3.12 89.2×29 78.78×21.18 76.778×19.178   0.278×0.278 6800,8080,SPI   SSD1322       Support PCAP 1
20×2
WEP002002A COG+FR+PCB 2.93 92.3×23.3 77.92×16.28 73.52×11.52   0.62×0.67 6800,8080,SPI,I2C   SSD1311       No
16×2
WO1602I3/I5 COG+PCB   66×28 40×9.98 38×7.98   0.36×0.43 I2C   ST7032i
128×64
WO12864K COG   89.7×49.8 66.8×35.5 63.98×31.98   0.48×0.48 6800,8080,SPI   ST7565V
128×64
WO12864K1 COG   89.7×49.8 66.8×35.5 63.98×31.98   0.48×0.48 6800,8080,SPI   ST7565P
128×128
WO128128A2 COG+PCB   60×62.79 42×42 44×44   0.308×0.308 6800,8080,SPI,I2C   ST75161
240×128
WO240128B2 COG+PCB   140×84 114×64 107.98×57.58   0.43×0.43 6800,8080,SPI   ST7586S
256×128
WO256128A2 COG+PCB   93×54 70.7×38.8 66.54×33.26   0.24×0.24 6800,8080,SPI,I2C   ST75256
