Model No. WF70D5SWAHLNGA
►Size : 7 inch
►Resolution : 1024x600 dots
►Glass Cover Display
►View Direction : 80/80/80/80 (IPS)
►Interface : LVDS
►Driver IC：JD9165BA
►Control-Board : No
►Brightness(cd/m²) : 1000
►Frame Through Hole : No
►Touch Screen : projected capacitive touchscreen
►Detect Point : 5 Fingers
►Operating Temperature : -30~+85°C (Wide Temperature)
The WF70D5SWAHLNGA is a 7-inch high-brightness, wide-temperature TFT display module with a glass cover display, featuring a projected capacitive touch panel (PCAP) and enhanced cover glass for added durability. This display is designed to withstand harsh environments, offering protection against scratches and impact. It boasts a 1024×600 resolution, JD9165BA driver IC, and LVDS interface, with 1000 cd/m² brightness and a 1000:1 contrast ratio, ensuring exceptional visibility even in outdoor or high-ambient-light settings. This makes it perfect for applications such as digital signage, industrial equipment, self-service kiosks, and automotive displays.
With IPS technology, it provides an 80° wide viewing angle, delivering stable colors and clarity from different perspectives. The LVDS interface ensures high-speed, long-distance data transmission with strong anti-interference capabilities.
The WF70D5 series shares the same active area size as the WF70A8 series but introduces ultra-wide temperature operation (-30°C to +85°C), making it suitable for demanding environments. Unlike the WF70A8 series, this model is specifically designed for applications requiring high brightness and durability, such as outdoor equipment and automotive displays.
Additionally, the GT911 touch IC supports the I2C interface and 5-point touch, enhancing touch responsiveness and durability for HMI interfaces, self-service kiosks, and medical equipment.
| Item | Dimension | Unit |
|---|---|---|
| Size | 7.0 | inch |
| Dot Matrix | 1024 × RGB × 600(TFT) | dots |
| Module dimension | 202.0(W) × 135.5(H) × 8.4(D) | mm |
| Active area | 154.2144 × 85.92 | mm |
| Pixel pitch | 0.1506 × 0.1432 | mm |
| LCD type | TFT, Normally Black, Transmissive | |
| View Angle | 80/80/80/80 | |
| TFT Driver IC | JD9165BA | |
| Backlight Type | LED, Normally White | |
| TFT Interface | LVDS | |
| PCAP IC | GT911 | |
| PCAP Interface | I2C | |
| PCAP FW Version | 67 | |
| PCAP Resolution | 1024*600 | |
| Touch Panel | Projected capacitive touch panel (PCAP) | |
| Surface | Glare | |
| Item | Symbol | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Operating Temperature | TOP | -30 | － | +85 | ℃ |
| Storage Temperature | TST | -30 | － | +85 | ℃ |
| Item | Symbol | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| Power voltage | VDD | 3.0 | 3.3 | 3.6 | V |
| Analog Power | AVDD | - | 11 | - | V |
| TFT Gate ON Voltage | VGH | 19.5 | 20 | 20 | V |
| TFT Gate OFF Voltage | VGL | -8.5 | -8 | -7.5 | V |
| TFT Common Voltage | Vcom | - | 4.9 | - | V |
| Power Current | IDD | - | 18 | 27 | mA |
| Analog Power Current | IAVDD | - | 20.94 | - | mA |
| TFT Gate ON Current | IVGH | - | 1.5 | - | mA |
| TFT Gate OFF Current | IVGL | - | 1.5 | - | mA |
| TFT Common Current | IVCOM | - | 1 | - | uA |
| Supply CTP | VDDT | 3.0 | 3.3 | 3.5 | V |
| ICTP | － | 16 | 24 | mA |
| Parameter | Symbol | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| LED current | － | － | 240 | － | mA |
| LED voltage | VLED+ | 16.2 | 19.2 | 21.0 | V |
| LED Life Time | － | 50,000 | － | － | Hr |
| Pin No. | Symbol | Function |
|---|---|---|
| 1 | VCOM | Common Voltage |
| 2 | VDD | Digital circuit |
| 3 | VDD | Digital circuit |
| 4 | NC | No connection |
| 5 | RESET | Global reset pin |
| 6 | STBYB | Standby mode, Normally pulled high STBYB = “1”, normal operation STBYB = “0”, timing controller, source driver will turn off, all output are High-Z |
| 7 | GND | Ground |
| 8 | RXIN0- | Negative LVDS differential data input |
| 9 | RXIN0+ | Positive LVDS differential data input |
| 10 | GND | Ground |
| 11 | RXIN1- | Negative LVDS differential data input |
| 12 | RXIN1+ | Positive LVDS differential data input |
| 13 | GND | Ground |
| 14 | RXIN2- | Negative LVDS differential data input |
| 15 | RXIN2+ | Positive LVDS differential data input |
| 16 | GND | Ground |
| 17 | RXCLKIN- | Negative LVDS differential clock input |
| 18 | RXCLKIN+ | Positive LVDS differential clock input |
| 19 | GND | Ground |
| 20 | RXIN3- | Negative LVDS differential data input |
| 21 | RXIN3+ | Positive LVDS differential data input |
| 22 | GND | Ground |
| 23 | NC | No connection |
| 24 | NC | No connection |
| 25 | GND | Ground |
| 26 | NC | No connection |
| 27 | NC | No connection |
| 28 | SELB | 6bit/8bit mode select H:6bit / L:8bit |
| 29 | AVDD | Power for Analog Circuit |
| 30 | GND | Ground |
| 31 | VLED- | LED_ Cathode |
| 32 | VLED- | LED_ Cathode |
| 33 | L/R | Horizontal inversion |
| 34 | U/D | Vertical inversion |
| 35 | VGL | Negative power for TFT |
| 36 | NC | No connection |
| 37 | NC | No connection |
| 38 | VGH | Positive power for TFT |
| 39 | VLED+ | LED_ Anode |
| 40 | VLED+ | LED_ Anode |
| Pin | Symbol | Function |
|---|---|---|
| 1 | VSS | Ground for analog circuit |
| 2 | VDDT | Power Supply : +3.3V |
| 3 | SCL | I2C clock input |
| 4 | NC | No connect |
| 5 | SDA | I2C data input and output |
| 6 | NC | No connect |
| 7 | /RST | External Reset, Low is active |
| 8 | NC | No connect |
| 9 | /INT | External interrupt to the host |
| 10 | VSS | Ground for analog circuit |
