7 inch 1024x600 with RGB interface TFT Display

Model No. WF70A8SYAHDNN0

►Size : 7 inch
►Resolution : 1024x600 dots
►View Direction : IPS
►Interface : RGB
►TFT Driver IC : EK79001HK-S + EK73215BCGA
►Control-Board : No
►Brightness(cd/m²) : 1100
►Frame Through Hole : No
►Touch Screen : No
►Operating Temperature : -20~+70°C

Description

WF70A8SYAHDNN0 TFT LCD Display Module delivers exceptional performance across diverse applications. This 7-inch module features a high-resolution 1024 x 600 pixel display and an active area of 154.2144 x 85.92 mm, ensuring clear and detailed visuals.

The WF70A8SYAHDNN0 utilizes TFT technology with a Normally Black, Transmissive LCD type and an IPS panel that provides wide 85/85/85/85-degree viewing angles, ensuring a vivid display experience. Its 16:9 aspect ratio, paired with a high brightness of 1100 cd/m2 and a contrast ratio of 800:1, enhances visibility in various lighting conditions.

With EK79001HK-S + EK73215BCGA driver ICs and a 24-bit RGB interface, this module seamlessly integrates into UAV controllers, industrial equipment, medical devices, smart home systems, and multifunctional office equipment. WF70A8 series that is option in LVDS, MIPI and RGB interface depend on customer MCU request.

The WF70A8SYAHDNN0 is designed with a LED backlight (Normally White) and anti-glare surface, ensuring optimal visibility and durability. Its power-efficient operation, ranging from 3.0 V to 3.6 V (typical value: 3.3V), enhances its suitability for diverse environments.



Versatile 7-inch TFT Displays - Ideal for UAVs, Medical Devices & More

DRAWING

7 inch 1024x600 with RGB interface TFT Display - WF70A8SYAHDNN0

SPECIFICATIONS

General Specifications

Item Dimension Unit
Size 7.0 inch
Dot Matrix 1024 x RGBx600(TFT) dots
Module dimension 169.9(W) x 103.4(H) x 5.6(D) mm
Active area 154.2144 x 85.92 mm
Pixel pitch 0.1506 x 0.1432 mm
LCD type TFT, Normally Black, Transmissive
Viewing Angle 85/85/85/85
Aspect Ratio 16:9
Driver IC EK79001HK-S + EK73215BCGA
Interface 24bit RGB
Backlight Type LED, Normally White
Touch Panel Without Touch Panel
Surface Anti-Glare

Absolute Maximum Ratings

Item Symbol Min Typ Max Unit
Operating Temperature TOP -20 +70
Storage Temperature TST -30 +80

Electrical Characteristics

Item Symbol Values Unit
Min. Typ. Max.
Power voltage VCC 3.0 3.3 3.6 V
Analog Power AVDD 8.9 9.0 9.1 V
TFT Gate ON Voltage VGH 17 18 19 V
TFT Gate OFF Voltage VGL -6.5 -6.0 -5.5 V
TFT Common Voltage Vcom 3.0 3.15 3.3 V
Current for Driver IDD - 85 130 mA
Power Current IAVDD - 20 - mA
TFT Gate ON Current IVGH - 1 - mA
TFT Gate OFF Current IVGL - 1 - mA
TFT Common Current IVCOM - 1 - mA

Interface

Pin No. Symbol Function
1 VLED+ LED Anode
2 VLED+ LED Anode
3 VLED- LED Cathode
4 VLED- LED Cathode
5 GND Ground
6 VCOM Common voltage
7 VCC Power for Digital Circuit
8 MODE DE/SYNC mode select
9 DE Data Input Enable (DEN)
10 VS Vertical Sync Input (VSD)
11 HS Horizontal Sync Input (HSD)
12 B7 Blue data(MSB)
13 B6 Blue data
14 B5 Blue data
15 B4 Blue data
16 B3 Blue data
17 B2 Blue data
18 B1 Blue data
19 B0 Blue data(LSB)
20 G7 Green data(MSB)
21 G6 Green data
22 G5 Green data
23 G4 Green data
24 G3 Green data
25 G2 Green data
26 G1 Green data
27 G0 Green data(LSB)
28 R7 Red data(MSB)
29 R6 Red data
30 R5 Red data
31 R4 Red data
32 R3 Red data
33 R2 Red data
34 R1 Red data
35 R0 Red data(LSB)
36 GND Power Ground
37 DCLK Sample clock (CLK)
38 GND Power Ground
39 L/R Left / right selection
40 U/D Up/down selection
41 VGH Gate ON Voltage
42 VGL Gate OFF Voltage
43 AVDD Power for Analog Circuit
44 RESET Global reset pin.
45 NC No connection
46 VCOM Common Voltage
47 DITHB Dithering function
48 GND Power Ground
49 NC No connection
50 NC No connection
