320x32 Monochrome Graphic LCD Display – 4.24" STN COG Module

Model No. WO32032A

►COG LCD Display
►Type: Graphic
►Structure: COG
►Size: 4.24"
►Display Format : 320x32 dots
►IC: ST7586S
►+3V power supply
►1/32 duty cycle
►Interface : SPI

Description

The WO32032A is a 4.24-inch monochrome graphic LCD display module featuring a 320x32 resolution and built with a COG (Chip-on-Glass) structure. This monochrome STN LCD is ideal for displaying icons, messages, and status indicators in compact devices such as control panels, handheld instruments, medical devices, and industrial monitoring systems.

With an active area of 106.865 × 12.85 mm, this module integrates the ST7586S controller and supports both 4-Line SPI and 3-Line SPI serial interfaces, selectable via software or hardware. A single 3.0V power supply drives both the module and its LED backlight, simplifying integration and enhancing energy efficiency.

The built-in booster circuit generates the necessary Vop, minimizing the need for external components and enabling software-adjustable contrast to suit various lighting environments. A two-piece LED backlight structure ensures even illumination and long-term reliability.

This monochrome LCD module is available in two display types:

  • FSTN (Transflective, Positive Polarizer)
  • DFSTN (Transmissive, Negative Polarizer)


Other configurations are available upon request. Contact us for more details about our 320x32 graphic LCD solutions.

DRAWING

WO32032A

Data source ref: WO32032A-TFH#

SPECIFICATIONS

Mechanical Data

Item Dimension Unit
Number of dots 320 x 32
Module dimension 114.32 x 27.56 x 5.6 mm
View area 109.12 x 15.26 mm
Active area 106.865 x 12.85 mm
Dot size 0.319 x 0.388 mm
Dot pitch 0.334 x 0.402 mm
Drive Method 1/32Duty,1/9 Bias
Backlight Type LED
IC ST7586S
Interface 3-Line SPI/ 4-Line SPI

Absolute Maximum Ratings

Item Symbol Min Typ Max Unit
Operating Temperature TOP -20 +70
Storage Temperature TST -30 +80
Digital Power Supply Voltage VDDI -0.3 3.6 V
LCD Power supply voltage V0-XV0 -0.3 19.0 V
Input Voltage VIN -0.3 VDDI+0.3 V

Electrical Characteristics

Item Symbol Condition Min Typ Max Unit
Digital Operating Voltage VDDI-VSS 2.7 3.0 3.3 V
Analog Operating Voltage VDDA-VSS 2.7 3.0 3.3
Supply Voltage For LCM V0-XV0 Ta=-20℃
Ta=25℃
Ta=70℃

9.8

10.0

10.2
V
V
V
Input High Volt. VIH 0.7 VDD VDD V
Input Low Volt. VIL VSS 0.3 VDD V
Output High Volt. VOH 0.8 VDD VDD V
Output Low Volt. VOL VSS 0.2 VDD V
Supply LCM Current IDD VDD=3.0V 1.1 2.0 mA

Interface Pin Function

Pin No. Symbol Function
1 ESD_GND ESD_Ground
2 SCL Serial clock line
3 SDA Serial data line
4 A0 The function of this pin is different in parallel and serial interface.
In serial interface: this pad will be used as SCL (serial-clock) input
5 RSTB Reset input pin
6 IF1 These pins select interface operation mode.
IF1 MPU interface type
H 4-Line
L 3-Line
7 CSB Chip select input pin
8 VDDI Power supply for Digital Operating Voltage
9 VD1 VD1I is the power source of digital circuits.
10 VSS Ground
1 VDDA Power supply for Analog Operating Voltage
12 VM VM is the power of SEG-drivers
13 V0 Positive operating voltage of COM-drivers.
14 XV0 Negative operating voltage of COM-drivers.
15 VG VG is the power of SEG-drivers
16 K LED-
17 A LED+
18 ESD_GND ESD_Ground
