Model No. WFN0460B2T0YADNT000
►Size : 4.6 inch
►Resolution : 800x320 dots
►View Direction : IPS
►Interface : RGB
►Driver IC : ST7262
►Control-Board : Without control board
►Brightness(cd/m²) : 350
►Frame Through Hole : No
►Touch Screen : Resistive Touch Screen
The WFN0460B2T0YADNT000 is a 4.6-inch bar type TFT LCD display with 800x320 resolution, using an IPS panel for wide viewing angles (80/80/80/80) and 350 cd/m² brightness. It adopts a normally black, transmissive TFT with the ST7262 driver IC and supports 24-bit RGB interface.
This model features a resistive touch panel, providing precise touch input suitable for applications where resistive touch is preferred.
With compact dimensions, bar-type aspect ratio, and anti-glare surface treatment, this display is ideal for horizontal layouts or limited spaces. It is particularly applicable in DJ mixers, digital keyboards, audio mixers, industrial control systems, medical devices, self-service kiosks, and other equipment requiring reliable resistive touch functionality.
For applications requiring capacitive touch and higher brightness, the WFN0460B2S0YADNC000 model from the same series is available as an alternative.
| Item | Dimension | Unit |
|---|---|---|
| Size | 4.6 | inch |
| Dot Matrix | 800 × RGB × 320(TFT) | dots |
| Module dimension | 120.7 (W) × 56.16 (H) × 4.2 | mm |
| Active area | 108.0 (W) × 43.2 (H) | mm |
| Dot pitch | 0.135(W) × 0.135(H) | mm |
| LCD type | TFT, Normally Black, Transmissive | |
| View Direction | 80/80/80/80 | |
| Aspect Ratio | Bar Type | |
| TFT Driver IC | ST7262 or equivalent | |
| TFT Interface | 24 bit R.G.B. | |
| Touch Panel | Resistive Touch Panel | |
| Surface | Anti-Glare | |
| Item | Symbol | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Operating Temperature | TOP | -20 | － | +70 | ℃ |
| Storage Temperature | TST | -30 | － | +80 | ℃ |
| Item | Symbol | Values | Unit | ||
|---|---|---|---|---|---|
| Min. | Typ. | Max. | |||
| Power voltage | VCC | 3.1 | 3.3 | 3.6 | V |
| Current for Driver(Black) | ICC | - | 56.0 | 85.0 | mA |
| Item | Symbol | Values | Unit | ||
|---|---|---|---|---|---|
| Min. | Typ. | Max. | |||
| Voltage for LED backlight | VLED | 16.2 | 18.0 | 19.8 | V |
| Current for LED backlight | ILED | - | 40 | - | mA |
| LED life time | - | 50,000 | - | - | Hr |
| Pin | Symbol | Function |
|---|---|---|
| 1 | VLED- | Power for LED backlight (Cathode) |
| 2 | VLED+ | Power for LED backlight (Anode) |
| 3 | GND | Power Ground |
| 4 | VCC | Power voltage |
| 5 | R0 | Red data (LSB) |
| 6 | R1 | Red data |
| 7 | R2 | Red data |
| 8 | R3 | Red data |
| 9 | R4 | Red data |
| 10 | R5 | Red data |
| 11 | R6 | Red data |
| 12 | R7 | Red data(MSB) |
| 13 | G0 | Green data(LSB) |
| 14 | G1 | Green data |
| 15 | G2 | Green data |
| 16 | G3 | Green data |
| 17 | G4 | Green data |
| 18 | G5 | Green data |
| 19 | G6 | Green data |
| 20 | G7 | Green data(MSB) |
| 21 | B0 | Blue data(LSB) |
| 22 | B1 | Blue data |
| 23 | B2 | Blue data |
| 24 | B3 | Blue data |
| 25 | B4 | Blue data |
| 26 | B5 | Blue data |
| 27 | B6 | Blue data |
| 28 | B7 | Blue data(MSB) |
| 29 | GND | Power Ground |
| 30 | DCLK | Sample clock |
| 31 | DISP | Display on/off |
| 32 | HSYNC | Horizontal sync signal applied to the RGB interface, default is negative polarity. |
| 33 | VSYNC | Vertical sync signal applied to the RGB interface, default is negative polarity. |
| 34 | DE | Data input enable |
| 35 | NC | No connection |
| 36 | GND | Power Ground |
| 37 | NC | No connection |
| 38 | NC | No connection |
| 39 | NC | No connection |
| 40 | NC | No connection |
