2.13-inch 122x250 4-Color Electronic Paper Display

Model No. WAA0213A2CNA6NXXX000

►Size: 2.13"
►Resolution : 122x250 dots
►Interface: MCU / SPI
►Touch Screen : Without touch screen
►The display can refresh Black, White, Red, and Yellow E-paper displays.
►Color Epaper Display

Description

WAA0213A2CNA6NXXX000 is a color electronic paper display module built on an active matrix TFT substrate, designed for applications requiring low power consumption and high contrast. The panel can display black, white, yellow, and red images, depending on the associated lookup table. Leveraging color epaper display technology, this technology provides exceptional reflectivity and ultra-wide viewing angles, ensuring clear and highly readable content, even in bright environments.

The integrated circuitry includes gate and source drivers, a timing controller, an oscillator, a DC-DC boost circuit, and memory to store the frame buffer and lookup tables. Additionally, circuits control VCOM and border settings, making this color epaper display ideal for outdoor, high-brightness, and portable applications, offering long-lasting, energy-efficient performance.

Features

  • Emphasizes vivid red and yellow colors for enhanced image clarity
  • High contrast for superior content visibility
  • High reflectance, ensuring excellent readability in bright environments
  • Ultra-wide viewing angle for consistent display quality from various angles
  • Ultra-low power consumption for extended operational life
  • Pure reflective mode for energy conservation
  • Bi-stable display that maintains content without power
  • Anti-glare hard-coated front surface to minimize sunlight interference
  • Low current deep sleep mode for extended battery life
  • On-chip display RAM for efficient operation
  • Waveform storage in on-chip OTP for efficient performance
  • Serial peripheral interface for external connections
  • On-chip oscillator for stable operation
  • On-chip booster and regulator control to generate VCOM, Gate, and Source voltages
  • I2C signal master interface for reading external temperature sensors
  • Available in COG package for compact integration

DRAWING

Color Electronic Paper Display, Color Epaper Display, Epaper Display Color, Electronic Paper Color - WAA0213A2CNA6NXXX000

SPECIFICATIONS

General Specifications

Parameter Specifications Unit
Screen Size 2.13 Inch
Display Resolution 122(H)×250(V) Pixel
Active Area 23.7046×48.55 mm
Pixel Pitch 0.1942×0.1943 mm
Pixel Configuration Rectangle
Outline Dimension 29.2(H)×59.2 (V) ×1.0(D) mm
Module Weight 3.3±0.5 g

Electrical Characteristics

Absolute Maximum Ratings

Parameter Symbol Rating Unit
Logic supply voltage VDD, AVDD, VDDIO, VDD1, VPP -0.3 to +6.0 V
Digital Input voltage VI -0.3 to VDDIO +0.3 V
Operating Temp range TOPR 0 to +40 ºC
Storage Temp range TSTG -25 to+70 ºC
Optimal Storage Temp TSTGo 23±2 ºC
Optimal Storage Humidity HSTGo 55±10 %RH

Interface

Input /Output Pin Assignment

No. Name I/O Description
1 NC   Do not connect with other NC pins
2 GDR O This pin is N-MOS gate control.
3 RESE P Current sense input for the control loop
4 NC   Do not connect with other NC pins
5 VSPL P Positive source voltage
6 TSCL I/O I2C clock for external temperature sensor
(I2C interface need external pull high resistance.)
Must pull high or low if not used.(Default low)
7 TSDA I/O I2C data for external temperature sensor
(I2C interface need external pull high resistance.)
Must pull high or low if not used.(Default low)
8 BS I Input interface setting.
9 BUSY_N O This pin indicates the driver status.
10 RET_N I Global reset pin. Low reset. (normal pull high)
11 DC I Serial communicaton Command/Data input
12 CSB I Serial communicaton chip select.
13 SCL I Serial communicaton clock select.
14 SDA I/O Serial communicaton data select.
15 VDDIO P IO voltage supply
16 VDD P Digital/Analog power
17 VSS P Digital ground
18 VDD_15V P 1.5V voltage input & output
19 VMTP P MTP program power
20 VSP C Positive source voltage
21 VGP C Positive gate voltage
22 VSN C Negative source voltage
23 VGN C Negative gate voltage
24 VCOM C VCOM output
