產品敘述
WEO016080A 是一款尺寸為 1.54 吋 的 COG 繪圖型 OLED 顯示器，解析度為 160x80 dots。模組尺寸為 43.5 x 22.5 mm，有效顯示區域為 35.02 x 17.50 mm，得益於其 COG 結構薄型設計厚度僅 1.41 mm。內建 SSD1320 IC，此模組支援 6800/8080 8-bit、4線 SPI 和 I2C 介面。提供 4-bit (16 Levels) 灰階，並實現高達 10,000:1 的對比度。
支援邏輯電源供應電壓範圍為 1.65V 至 3.3V (典型值為3V)，模組在 -40°C 至 +80°C 的溫度範圍內可靠運行，並能在 -40°C 至 +85°C 的儲存溫度下工作。適用於各種應用，包括網路產品、USB 測試儀、智慧手錶、電競鍵盤，以及智慧醫療設備如血氧機和皮膚分析儀，WEO016080A 以其清晰生動的顯示螢幕提升了顯示品質。
高解析度(160x80 dots) 和低功耗使得這款 OLED 顯示模組非常適合要求高性能和高效率的應用。
規格圖
Data source ref:WEO016080AWPP3N00000
產品規格
規格說明
| 項目 | 規格 | 單位 |
|---|---|---|
| 解析度 | 160 x 80 Dots | － |
| 模組尺寸 | 43.5 x 22.5 x 1.41 | mm |
| 有效區域 | 35.02 x 17.50 | mm |
| 像素大小 | 0.199 x 0.199 | mm |
| 像素間距 | 0.219 x 0.219 | mm |
| 顯示模式 | 被動矩陣 | |
| 顯示顏色 | 單色 | |
| 驅動方式 | 1/80 Duty | |
| 灰階 | 4 bits | |
| 介面 | 6800,8080,4-Wire SPI,I2C | |
| IC | SSD1320 | |
| 尺寸 | 1.54 吋 | |
最大絕對額定值
| 參數 | 符號 | 最小值 | 典型值 | 最大值 | 單位 |
|---|---|---|---|---|---|
| 邏輯電源電壓 | VDD | -0.3 | － | 4 | V |
| 顯示電源電壓 | VCC | 0 | － | 19 | V |
| 工作溫度 | TOP | -40 | － | +80 | °C |
| 儲存溫度 | TSTG | -40 | － | +85 | °C |
電氣特性
DC電氣特性
| 項目 | 符號 | 條件 | 最小值 | 典型值 | 最大值 | 單位 |
|---|---|---|---|---|---|---|
| 邏輯電源電壓 | VDD | － | 1.65 | 3.0 | 3.3 | V |
| 邏輯電源電壓 | VCC | － | 8.0 | 15.0 | 15.5 | V |
| 輸入高電壓 | VIH | － | 0.8×VDD | － | VDD | V |
| 輸入低電壓 | VIL | － | 0 | － | 0.2×VDD | V |
| 輸出高電壓 | VOH | － | 0.9×VDD | － | VDD | V |
| 輸出低電壓 | VOL | － | 0 | － | 0.1×VDD | V |
| VCC 供電電流 | ICC | VDD=3V,VCC=15V Display 50% Pixel ON |
－ | 14 | 21 | mA |
Pin功能定義
| No. | 符號 | 功能 | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | N.C. (GND) |
Reserved Pin (Supporting Pin) The supporting pin can reduce the influences from stresses on the function pins. This pin could be connected to external ground as the ESD protection circuit. |
|||||||||||||||
| 2 | VCC | Power Supply for OEL Panel This is the most positive voltage supply pin of the chip. It must be connected to external source. |
|||||||||||||||
| 3~4 | N.C. | Reserved Pin The N.C. pin between function pins are reserved for compatible and flexible design. |
|||||||||||||||
| 5 | BS1 | Communicating Protocol Select These pins are MCU interface selection input. See the following table:
|
|||||||||||||||
| 6 | BS2 | ||||||||||||||||
| 7 | VSS | Ground of Logic Circuit This is a ground pin. It also acts as a reference for the logic pins. It must be connected to external ground. |
|||||||||||||||
| 8 | IREF | Current Reference for Brightness Adjustment This pin is segment current reference pin. A resistor should be connected between this pin and VSS. Set the current at 10μA maximum. |
|||||||||||||||
| 9 | CS# | Chip Select This pin is the chip select input. The chip is enabled for MCU communication only when CS# is pulled low. |
|||||||||||||||
| 10 | RES# | Power Reset for Controller and Driver This pin is reset signal input. When the pin is low, initialization of the chip is executed. Keep this pin pull high during normal operation. |
|||||||||||||||
| 11 | D/C# | Data/Command Control This pin is Data/Command control pin. When the pin is pulled high, the input at D7~D0 is treated as display data. When the pin is pulled low, the input at D7~D0 will be transferred to the command register. In I2C mode, this pin acts as SA0 for slave address selection. |
|||||||||||||||
| 12 | R/W# | Read/Write Select or Write This pin is MCU interface input. When interfacing to a 68XX-series microprocessor, this pin will be used as Read/Write (R/W#) selection input. Pull this pin to “High” for read mode and pull it to “Low” for write mode. When 80XX interface mode is selected, this pin will be the Write (WR#) input. Data write operation is initiated when this pin is pulled low and the CS# is pulled low. When serial mode is selected, this pin must be connected to VSS. |
|||||||||||||||
| 13 | E/RD# | Read/Write Enable or Read This pin is MCU interface input. When interfacing to a 68XX-series microprocessor, this pin will be used as the Enable (E) signal. Read/write operation is initiated when this pin is pulled high and the CS# is pulled low. When connecting to an 80XX-microprocessor, this pin receives the Read (RD#) signal. Data read operation is initiated when this pin is pulled low and CS# is pulled low. When serial mode is selected, this pin must be connected to VSS. |
|||||||||||||||
| 14 | D0 | Host Data Input/Output Bus These pins are bi-directional data bus connecting to the MCU data bus. Unused pins are recommended to tie LOW. When serial interface mode is selected, D2, D1 should be tied together as the serial data input: SDIN, and D0 will be the serial clock input: SCLK. When I2C mode is selected, D2, D1 should be tied together and serve as SDAout, SDAin in application and D0 is the serial clock input, SCL. |
|||||||||||||||
| 15 | D1 | ||||||||||||||||
| 16 | D2 | ||||||||||||||||
| 17 | D3 | ||||||||||||||||
| 18 | D4 | ||||||||||||||||
| 19 | D5 | ||||||||||||||||
| 20 | D6 | ||||||||||||||||
| 21 | D7 | ||||||||||||||||
| 22 | VDD | Power Supply for Logic This is a voltage supply pin. It must be connected to external source. |
|||||||||||||||
| 23 | VCOMH | Voltage Output High Level for COM Signal This pin is the input pin for the voltage output high level for COM signals. A tantalum capacitor should be connected between this pin and VSS. |
|||||||||||||||
| 24 | VCC | Power Supply for OEL Panel This is the most positive voltage supply pin of the chip. It must be connected to external source. |
