10.1" 1024x600 IPS TFT LCD Module with RGB and Capacitive Touch

Model No. WF101JSYAHDNB0

►Size : 10.1 inch
►Resolution : 1024×600 dots
►View Direction : IPS
►Interface : RGB
►Driver IC : EK79001HN-S + EK73215BCGA
►Control-Board : No
►Brightness(cd/m2) : 900
►Frame Through Hole : No
►Touch Screen : Projected Capacitive Touch Panel (PCAP)
►Detect Point : 5 Fingers

Description

The 10.1-inch 1024x600 High Brightness IPS TFT LCD Module (Model: WF101JSYAHDNB0) is equipped with a Projected Capacitive Touch Panel (PCAP) and is designed for various industrial applications. This module combines excellent performance and reliability, providing clear and vibrant display effects in a range of environments. The model features built-in EK79001HN-S and EK73215BCGA TFT driver ICs, supports a 24-bit RGB interface, and utilizes an ILI2511 driver IC for the PCAP, supporting USB interface (I2C available) and 5-point touch functionality.

The module's display has a diagonal size of 10.1 inches with a resolution of 1024x600 pixels, ensuring that every detail is clearly presented. Its overall dimensions are 235 × 143 × 8.78 mm, making it convenient for installation in various devices. The active display area measures 222.72 × 125.28 mm, delivering excellent display quality for users to fully appreciate the detail of the screen.

This TFT LCD display module utilizes IPS panel technology, featuring wide viewing angles of up to 85 degrees, ensuring that colors remain true and consistent from any angle. Brightness can reach 900 cd/m² with a contrast ratio of 800:1, allowing for good readability even in bright environments, making it particularly suitable for touch-enabled entrance devices, elevator displays, smart home applications, medical equipment, and more.

Versatile Interface Options:

The WF101J series supports a variety of interfaces, including LVDS, MIPI, RGB, and HDMI connector (DVI signal), ensuring seamless integration into different systems. Whether you need a standard display or a touch-enabled module, the series offers flexible solutions tailored to your application.

Additionally, the operating temperature range of this display module is -20℃ to +70℃, with a storage temperature range of -30℃ to +80℃, making it suitable for stable operation under various conditions. The power supply requirement is a digital voltage of 3.0~3.6V, ensuring a balance between energy efficiency and performance. This model series also offers non-touch options, making it ideal for applications requiring basic display functionality.

Smart Retail Solutions - Service Robots: Smart Navigation for Enhanced Customer Experience, Instant Product Information Lookup. WF101JSYAHDNB0 TFT Display Module: Clear Floor Information Display, High Resolution with Touch Interaction

DRAWING

10.1 inch 1024x600 IPS TFT LCD Module with RGB and Capacitive Touch - WF101JSYAHDNB0

SPECIFICATIONS

General Specifications

Item Dimension Unit
Size 10.1 inch
Dot Matrix 1024 × RGB × 600 dots
Module dimension 235(W) × 143(H) × 8.78(D) mm
Active area 222.72 (H) × 125.28(V) mm
Pixel pitch 0.2175(W) × 0.2088(H) mm
LCD type TFT, Normally Black, Transmissive
Interface 24 bit RGB
Driver IC EK79001HN-S+EK73215BCGA or equivalent
Viewing Angle 85/85/85/85 (IPS)
Aspect Ratio 16:9
Backlight Type LED, Normally White
PCAP IC ILI2511 or equivalent
PCAP Interface USB (I2C available)
PCAP FW Version: V6.0.0.0.62.90.1.2
PCAP Resolution 16384*16384
Touch Panel Projected Capacitive Touch Panel (PCAP)
Surface Glare

Absolute Maximum Ratings

Item Symbol Min Typ Max Unit
Operating Temperature TOP -20 +70
Storage Temperature TST -30 +80

Electrical Characteristics

Typical Operation Conditions (At Ta = 25 °C,)

Item Symbol Min Typ Max Unit
Digital Power Supply Voltage For LCD VDD 3 3.3 3.6 V
Analog Power Supply Voltage AVDD 9.89 10.2 10.5 V
Gate On Power Supply Voltage VGH 19.4 20.0 20.6 V
Gate Off Power Supply Voltage VGL -10.3 -10.0 -9.7 V
Common Power Supply Voltage VCOM 4.0 4.3 4.6 V
Input logic high voltage VIH 0.7 Vcc - Vcc V
Input logic low voltage VIL 0 - 0.3 Vcc V
Supply PCAP VDDT 3.0 3.3 3.6 V
IVDDT - 90.5 115 V
USB_VDD 5V 4.4 5.0 5.5 V
I VDD 5V - 97.8 120 mA


Interface

TFT LCD Module

Pin No. Symbol Function
1 VLED+ LED Anode
2 VLED+ LED Anode
3 VLED- LED Cathode
4 VLED- LED Cathode
5 GND Ground
6 VCOM Common voltage
7 VCC Power for Digital Circuit
8 MODE DE/SYNC mode select
9 DE Data Input Enable (DEN)
10 VS Vertical Sync Input (VSD)
11 HS Horizontal Sync Input (HSD)
12 B7 Blue data(MSB)
13 B6 Blue data
14 B5 Blue data
15 B4 Blue data
16 B3 Blue data
17 B2 Blue data
18 B1 Blue data
19 B0 Blue data(LSB)
20 G7 Green data(MSB)
21 G6 Green data
22 G5 Green data
23 G4 Green data
24 G3 Green data
25 G2 Green data
26 G1 Green data
27 G0 Green data(LSB)
28 R7 Red data(MSB)
29 R6 Red data
30 R5 Red data
31 R4 Red data
32 R3 Red data
33 R2 Red data
34 R1 Red data
35 R0 Red data(LSB)
36 GND Power Ground
37 DCLK Sample clock (CLK)
38 GND Power Ground
39 L/R Left / right selection
40 U/D Up/down selection
41 VGH Gate ON Voltage
42 VGL Gate OFF Voltage
43 AVDD Power for Analog Circuit
44 RESET Global reset pin.
45 NC(BIST) No connection
46 VCOM Common Voltage
47 DITHB Dithering function
48 GND Power Ground
49 NC(FGND) No connection
50 NC(FGND) No connection

PCAP PIN Definition

Pin Symbol Function
1 USB_VSS System ground
2 USB_VDD 5V Power supply
3 USB_D+ Data +
4 USB_D- Data -
5 VSS System ground
6 SDA I2C data input and output
7 SCL I2C clock input
8 RST External Reset, Low is active
9 INT External interrupt to the host
10 VDDT 3.3 Power supply
