產品敘述
WEO012864AH是一款1.54吋COG繪圖型128x64 OLED顯示器。此COG OLED模組內建SH1106控制器IC可支援I2C、4線SPI串列介面和6800、8080並列介面。邏輯電壓範圍為1.65V~3.3V，典型值為3.0V，顯示電壓範圍為6.4V~13V，典型值為12.5V，驅動方式1/64 duty。華凌光電的WEO012864AH系列1.54吋OLED模組非常適合各種應用，包括醫療設備 (血氧機)、消費性電子產品 (MP3、無線麥克風接收器)、智能家电、檢測設備(USB電壓電流檢測器)和工業自動化。
主要特點和優點
高品質顯示器：WEO012864AH 系列提供高品質 OLED 顯示屏，具有出色的色彩精度、高對比度（10,000:1）和解析度（128x64 dots）。
小巧尺寸：模組採用 1.54 吋的小尺寸設計，非常適合便攜式設備和穿戴式裝置。
應用：
醫療設備：WEO012864AH 系列非常適合用於血糖儀、血壓計和其他醫療設備等醫療設備。
消費性電子產品：此模組適用於各種消費性電子產品，包括智慧手錶、健身追蹤器、電子遊標卡尺和其他穿戴式裝置。
工業自動化：OLED顯示器可用於工業自動化應用，例如溫度和濕度感測器以及其他監控設備。
智慧家庭設備：此模組可用於智慧家庭設備，例如照明系統和其他物聯網設備。
此模組工作溫度為-40℃至+ 80℃，儲存溫度為-40℃至+85℃。工作溫度範圍為-40℃至+80℃； 其儲存溫度範圍為-40℃至+85℃。 WEO012864AH系列有不同的ZIF FPC； 目前，我們提供24 pin和30 pin可選，如果客戶需要客製化FPC，歡迎與我們聯繫。
規格圖
Data source ref:WEO012864AHWPP3N00000
產品規格
規格說明
| 項目 | 規格說明 | 單位 |
|---|---|---|
| 點陣(解析度) | 128 × 64 | － |
| 模組尺寸 | 42.04 × 27.22 × 1.41 | mm |
| 有效區域 | 35.05 × 17.51 | mm |
| 像素大小 | 0.249 × 0.249 | mm |
| 像素間距 | 0.274 × 0.274 | mm |
| 顯示模式 | Passive Matrix 被動矩陣 | |
| 顯示顏色 | 單色 | |
| 驅動方式 | 1/64 Duty | |
| IC | SH1106 | |
| 介面 | 6800,8080,4線 SPI,I2C | |
| 尺寸 | 1.54 吋 | |
最大絕對額定值
| 參數 | 符號 | 最小值 | 最大值 | 單位 |
|---|---|---|---|---|
| 邏輯電源電壓 | VDD1 | -0.3 | 3.6 | V |
| 顯示電源電壓 | VPP | -0.3 | 14.5 | V |
| 工作溫度 | TOP | -40 | +80 | °C |
| 儲存溫度 | TSTG | -40 | +85 | °C |
電氣特性
| 項目 | 符號 | 條件 | 最小值 | 典型值 | 最大值 | 單位 |
|---|---|---|---|---|---|---|
| 邏輯電源電壓 | VDD1 | － | 1.65 | 3.0 | 3.3 | V |
| 顯示電源電壓 | VPP | － | 6.4 | 12.5 | 13.0 | V |
| 輸入高準位 | VIH | － | 0.8×VDD1 | － | VDD1 | V |
| 輸入低準位 | VIL | － | VSS | － | 0.2×VDD1 | V |
| 輸出高準位 | VOH | － | 0.8×VDD1 | － | VDD1 | V |
| 書出低準位 | VOL | － | VSS | － | 0.2×VDD1 | V |
| Display 50% Pixel on | IPP | VPP =12.5V | － | 13 | 20 | mA |
Pin功能定義
| No. | 符號 | 功能說明 | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | ESD_GND | ESD Ground pin | |||||||||||||||
| 2 | VSS | Ground. | |||||||||||||||
| 3 | VSS | Ground. | |||||||||||||||
| 4 | NC | No connection | |||||||||||||||
| 5 | VDD1 | Power supply input | |||||||||||||||
| 6 | IM1 | These are the MPU interface mode select pads.
(1) 0 is connected to VSS (2) 1 is connected to VDD1 |
|||||||||||||||
| 7 | IM2 | ||||||||||||||||
| 8 | /CS | This pad is the chip select input. When /CS = “L”, then the chip select becomes active, and data/command I/O is enabled. | |||||||||||||||
| 9 | /RES | This is a reset signal input pad. When /RES is set to “L”, the settings are initialized. The reset operation is performed by the /RES signal level. | |||||||||||||||
| 10 | A0 | This is the Data/Command control pad that determines whether the data bits are data or a command. A0 = “H”: the inputs at D0 to D7 are treated as display data. A0 = “L”: the inputs at D0 to D7 are transferred to the command registers. In I2C interface, this pad serves as SA0 to distinguish the different address of OLED driver. |
|||||||||||||||
| 11 | /WR (R/W) |
This is a MPU interface input pad. When connected to an 8080 MPU, this is active LOW. This pad connects to the 8080 MPU /WR signal. The signals on the data bus are latched at the rising edge of the /WR signal. When connected to a 6800 Series MPU: This is the read/write control signal input terminal. When R/= “H”: Read. When R/W= “L”: Write. |
|||||||||||||||
| 12 | E/RD | This is a MPU interface input pad. When connected to an 8080 series MPU, it is active LOW. This pad is connected to the /RD signal of the 8080 series MPU, and the data bus is in an output status when this signal is “L”. When connected to a 6800 series MPU, this is active HIGH. This is used as an enable clock input of the 6800 series MPU. When /RD = “H”: Enable. When /RD = “L”: Disable. |
|||||||||||||||
| 13-20 | D0~D7 | This is an 8-bit bi-directional data bus that connects to an 8-bit or 16-bit standard MPU data bus. When the serial interface is selected, then D0 serves as the serial clock input pad (SCL) and D1 serves as the serial data input pad (SI). At this time, D2 to D7 are set to high impedance. When the I2C interface is selected, then D0 serves as the serial clock input pad (SCL) and D1 serves as the serial data input pad (SDAI). At this time, D2 to D7 are set to high impedance. |
|||||||||||||||
| 21 | IREF | This is a segment current reference pad. A resistor should be connected between this pad and VSS. Set the current at 18.75uA. | |||||||||||||||
| 22 | VCOMH | This is a pad for the voltage output high level for common signals. A capacitor should be connected between this pad and VSS. |
|||||||||||||||
| 23 | VPP | OLED panel power supply. It could be supplied externally. A capacitor should be connected between this pad and VSS. |
|||||||||||||||
| 24 | ESD_GND | ESD Ground pin |
