Dispaly OLED 96x64 Gráfico 0,95 pulgada - WEO009664D

Dispaly OLED 96x64 Gráfico 0,95 pulgada

Modelo Nº WEO009664D

►Tipo: Gráfico
►Estructura: COG
►Tamaño : 0.95 inch
►Matriz de puntos 96 x 64
►IC：SSD1315
►Fuente de alimentación de 3V
►1/64 duty
►Interfaz : 6800, 8080, SPI, I2C
►Color de la pantalla: Blanco / Amarillo

DESCARGAR PDF

CÓDIGO DEMO AÑADIR A PREGUNTA

PREV. VOLVER A LA LISTA SIGUIENTE

Descripción

El WEO009664D es un módulo de pantalla OLED de 0,95 pulgadas con una resolución de 96×64 píxeles. Este OLED de matriz pasiva adopta una estructura COG (Chip on Glass) e integra el IC SSD1315; admite interfaces paralelas de 8 bits 6800/8080, I²C y SPI. El voltaje de alimentación lógica es de 3V con un ciclo de conducción de 1/64, y la corriente típica de la pantalla bajo un patrón de tablero de ajedrez al 50% es de 6mA @ 12Vcc. La relación de contraste es de 10,000:1 y la vida útil operativa puede alcanzar hasta 50,000 horas. Este módulo OLED puede operar en temperaturas de -40℃ a +80℃ y almacenarse entre -40℃ y +85℃.

La parte visible del OLED mide 0,95 pulgadas en diagonal con 96×64 píxeles, lo que lo hace muy adecuado para dispositivos portátiles. En comparación con los LCD convencionales, ofrece mayor brillo, contraste superior, ángulos de visión más amplios y menor consumo de energía. El módulo COG OLED WEO009664D es ultradelgado, liviano y eficiente en energía, ideal para dispositivos portátiles, medidores, equipos de red inteligente, aplicaciones IoT y más.

DIBUJO

OLED Graphic 0.95 inch 96x64 - WEO009664D

Data source ref: WEO009664DLPP3N00000

ESPECIFICACIONES

Datos mecánicos

Elemento	Dimensión	Unidad
Matriz de puntos	96 x 64 puntos	－
Dimensión del módulo	24.90 × 22.95 ×1.61	mm
zona activa	19.946 × 13.418	mm
Tamaño del punto	0.184 × 0.186	mm
Distancia entre puntos	0.208 × 0.210	mm
Modo de visualización	Matriz pasiva
Color de la pantalla	Monocromos
Drive Duty	1/64 Duty
IC	SSD1315
Interfaz	6800,8080,4-Wire SPI,I2C
Tamaño (Diagonal)	0.95 pulgada

Valores nominales máximos absolutos

Parameter	Símbolo	Valor mín.	Valor típico	Valor máx.	Unidad
Supply Voltage for Logic	VDD	-0.3	-	4	V
Supply Voltage for Display	VCC	0	-	18	V
Temperatura de funcionamiento	TOP	-40	-	+80	°C
Temperatura de almacenamiento	TSTG	-40	-	+85	°C

Características electrónicas

DC Características electrónicas

Elemento	Símbolo	Condición	Valor mín.	Valor típico	Valor máx.	Unidad
Supply Voltage for Logic	VDD	－	1.65	3.0	3.3	V
Supply Voltage for Display	VCC	－	7.5	12.0	12.5	V
Input High Volt.	VIH	－	0.8×VDD	－	VDD	V
Input Low Volt.	VIL	－	0	－	0.2×VDD	V
Output High Volt.	VOH	Iout = 100uA	0.9×VDD	－	VDD	V
Output Low Volt.	VOL	Iout = 100uA	0	－	0.1×VDD	V
50% Check Board operating Current	ICC	－	－	6	9	mA

Función interfaz Pin

No.

Símbolo

Función

No connection

VCC

Power supply for panel driving voltage. This is also the most positive power voltage supply pin.

VSS

Ground pin. It must be connected to external ground.

No connection

VDD

Power supply pin for core logic operation.

BS1

MCU bus interface selection pins. Select appropriate logic setting as described in the following table. BS2, BS1 are pin select

BS[2:1]	Interface
00	4 line SPI
01	I2C
11	8-bit 8080 parallel
10	8-bit 6800 parallel

Note
(1) 0 is connected to VSS
(2) 1 is connected to VDD

BS2

CS#

This pin is the chip select input connecting to the MCU.
The chip is enabled for MCU communication only when CS# is pulled LOW (active LOW).

RES#

This pin is reset signal input. When the pin is pulled LOW, initialization of the chip is executed. Keep this pin HIGH (i.e. connect to VDD) during normal operation.

D/C#

This pin is Data/Command control pin connecting to the MCU.
When the pin is pulled HIGH, the data at D[7:0] will be interpreted as data.
When the pin is pulled LOW, the data at D[7:0] will be transferred to a command register.
In I2C mode, this pin acts as SA0 for slave address selection.

R/W#

This is read / write control input pin connecting to the MCU interface.
When interfacing to a 6800-series microprocessor, this pin will be used as Read/Write (R/W#) selection input. Read mode will be carried out when this pin is pulled HIGH (i.e. connect to VDD) and write mode when LOW.
When 8080 interface mode is selected, this pin will be the Write (WR#) input. Data write operation is initiated when this pin is pulled LOW and the chip is selected.
When serial or I2C interface is selected, this pin must be connected to VSS.

E/RD#

This pin is MCU interface input.
When 6800 interface mode is selected, this pin will be used as the Enable (E) signal. Read/write operation is initiated when this pin is pulled HIGH and the chip is selected.
When 8080 interface mode is selected, this pin receives the Read (RD#) signal. Read operation is initiated when this pin is pulled LOW and the chip is selected.
When serial or I2C interface is selected, this pin must be connected to VSS.

These are 8-bit bi-directional data bus to be connected to the microprocessor’s data bus. When serial interface mode is selected, D0 will be the serial clock input: SCLK; D1 will be the serial data input: SDIN.
When I2C mode is selected, D2, D1 should be tied together and serve as SDAout, SDAin in application and D0 is the serial clock input, SCL.

IREF

This is segment output current reference pin.
When external IREF is used, a resistor should be connected between this pin and VSS to maintain the IREF current at 30uA.

VCOMH

COM signal deselected voltage level.
A capacitor should be connected between this pin and VSS.

VCC

Power supply for panel driving voltage. This is also the most positive power voltage supply pin.

VLSS

This is an analog ground pin. It should be connected to VSS externally.

No connection
