华凌 WFN0240A2T0GADNN000 为一款 2.4 英寸半透射式 TFT-LCD 模块,专为提升室内与户外环境下的可视性而设计。此模块具备 240x320 像素分辨率,内建 ST7789 驱动 IC,提供稳定效能并易于系统整合。支持 MCU、SPI 与 RGB 多种接口,为工程师带来更高的设计弹性。搭配抗眩光表面处理及 -20℃ 至 +70℃ 的操作温度范围,适用于手持装置、工业控制器与医疗设备等对可靠可读性与耐用性有严格需求的应用。


| 项目 | 规格 | 单位 |
|---|---|---|
| 尺寸 (对角线) | 2.4 | 英寸 |
| 分辨率 | 240 × RGB × 320(TFT) | dots |
| 模块尺寸 | 42.72 × 60.26 × 2.63 | mm |
| 有效区域 | 36.72 × 48.96 | mm |
| 像素间距 | 0.153 × 0.153 | mm |
| LCD类型 | TFT, 白色,半透射式 | |
| 视角 | 3点钟方向 | |
| TFT界面 | 8/9/16/18Bit MCU 3/4SPI+16/18Bit RGB 3-line/4-line Serial |
|
| 背光类型 | LED ,平常白 | |
| TFT驱动IC | ST7789 或相容IC | |
| 触控面板 | 无触控面板 | |
| 表面 | 防眩光 | |
| 项目 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 工作温度 | TOP | -20 | - | +70 | ℃ |
| 储存温度 | TST | -30 | - | +80 | ℃ |
| 项目 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 数字电源电压 | VCI | 2.4 | 3.3 | 3.6 | V |
| 逻辑电压 | IOVCC | 1.65 | 1.8 | 3.3 | V |
| 正常模式工作电流 | IDD | -- | 5 | 10 | mA |
| 输入电压 | VIH | 0.7 IOVCC | IOVCC | V | |
| VIL | GND | 0.3 IOVCC | V | ||
| 输出电压 | VOH | 0.8 IOVCC | IOVCC | V | |
| VOL | GND | 0.2 IOVCC | V |
| 项目 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| LED电流 | - | - | 80 | - | mA |
| LED电压 | VLEDA | 2.7 | 3.1 | 3.3 | V |
| LED使用寿命 | - | 50,000 | - | - | Hr |
| Pin No | 符号 | 说明 | I/O |
|---|---|---|---|
| 1 | NC | No connection | -- |
| 2 | NC | No connection | -- |
| 3 | NC | No connection | -- |
| 4 | NC | No connection | -- |
| 5 | GND | Ground. | P |
| 6 | GND | Ground. | P |
| 7 | VCC | Supply voltage(3.3V). | I |
| 8 | VCC | Supply voltage(3.3V). | I |
| 9 | IOVCC | Power Supply for I/O System. | I |
| 10 | SDO | SPI interface output pin. -The data is output on the falling edge of the SCL signal. -If not used, let this pin open. |
O |
| 11-28 | DB17-DB0 | 18-bit parallel bi-directional data bus for MCU system and RGB i nterface mode. Fix to GND level when not in use |
I/O |
| 29 | DIN(SDA) | Serial input signal. The data is latched on the rising edge of the SCL signal. fix this pin at IOVCC or GND when not in use. |
I/O |
| 30 | PCLK | Dot clock signal for RGB interface operation. Fix this pin at IOVCC or GND when not in use. |
I |
| 31 | DE | Data enable signal for RGB interface operation. fix this pin at IOVCC or GND when not in use. |
I |
| 32 | HSYNC | Line synchronizing signal for RGB interface operation. fix this pin at IOVCC or GND when not in use. |
I |
| 33 | VSYNC | Frame synchronizing signal for RGB interface operation. fix this pin at IOVCC or GND when not in use. |
I |
| 34 | RD | Read enable in 8080 MCU parallel interface. -If not used, please fix this pin at IOVCC or DGND. |
I |
| 35 | WR(SPI-RS) | -Write enable in MCU parallel interface. Display data/command selection pin in 4-line serial interface. Second Data lane in 2 data lane serial interface. -If not used, please fix this pin at IOVCC or DGND. |
I |
| 36 | RS(SPI-SCL) | -Display data/command selection pin in parallel interface. -This pin is used to be serial interface clock. RS=’1’: display data or parameter. RS=’0’: command data. -If not used, please fix this pin at IOVCC or DGND. |
I |
| 37 | CS | Chip select input pin (“Low” enable). fix this pin at IOVCC or GND when not in use. |
I |
| 38 | RESET | This signal will reset the device and must be applied to properly initialize the chip. |
I |
| 39 | IM0 | 18-bit parallel bi-directional data bus for MCU system and RGB interface mode. Fix to GND level when not in use |
I |
| 40 | IM1 | ||
| 41 | IM2 | ||
| 42 | NC | No connection | - |
| 43 | LEDA | Anode pin of backlight | P |
| 44 | NC | No connection | - |
| 45 | LEDK | Cathode pin OF backlight | P |
