JAN, 2023 Winstar News
Issue No. 167

Welcome to read the 1st released issue of the Winstar Newsletter in the year 2023. This year is a special year as we will be celebrating our 25th anniversary, and over all these years, we have shown that we always take very well-considered steps with a view to further growth solutions. Significantly, we broke a record and hit a revenue high in 2022. Which makes 2022 has been a landmark year for Winstar. We would like to thank all of our customers for your support and business, we will continue to provide professional service as we always do. We are ready to forge ahead to a new chapter with customers for the next 25 years and more. Happy Chinese New Year!!



Holiday Notice


Winstar Display Taiwan HQ, branches, and China factories will be closed from January 20 ~29, 2023 for the Chinese New Year Holiday. We will resume working on January 30, 2023.
Below are the last shipping date and the first shipping date for this period as reference. Shipments and deliveries before and after Chinese New Year might be moving unstable since the impact of the COVID-19 epidemic and the long holiday period. Please work with our sales persons closely before the holiday if your shipment might be affected. Thank you.
2023-winstar-shipping
Shipping From Taiwan:
 ■ Last shipping date:January 18, 2023
 ■ First shipping date:January 30, 2023

Shipping From China:
 ■ Last shipping date:January 16, 2023
 ■ First shipping date:January 30, 2023

Exhibition News: Embedded World 2023 Nuremberg Germany



Winstar is going to demonstrate our technology and products portfolio at Embedded World 2023 in Nuremberg , from March 14th to 16th, 2023, at booth 1-460. We will be showcasing a variety of TFT, OLED, System Integration, and a comprehensive range of industrial displays solutions.

winstar-embedded-world-2023-nurnberg-germany

Welcome to visit us !

Date: March 14~March 16, 2023
Location: Embedded World,Nuremberg Germany
Booth No: At Booth 1-460.

All about the exhibition

This issue, let's catch up with our Entry Level UART TFT Display new products and a technical article regarding “How to Switch Pages for Canbus SmartDisplay Products”.

(1) F Series of Entry Level UART TFT Display Introduction
(2) Model No.WL0F00035000LNFAAEA00
(3) Model No.WL0F00043000UNFAAEA00
(4) Model No.WL0F00043000UGFAAEA00
(5) Model No.WF70C4SIAGDNG0
(6) Tech Article:How does the HOST switch page with SmartDisplay products - CANbus



Entry Level UART TFT Display Introduction

Winstar F Series of Entry Level UART TFT Display is an easily accessible system for users to explore the colorful display on their applications.

Entry Level UART TFT is designed with UART (Universal Asynchronous Receiver/Transmitter) communication interface, and it supports backlight brightness adjustment, PWM (Pulse-width modulation) signal output, and 4 digital input pins.

We have also designed an app called “Clever system User API” for users to do the firmware programming more easily. Besides, Winstar has also provided the “SmartDisplay Entry User Guide” for customer development & operation reference.

Winstar Entry Level UART TFT Display provides below key advantages for your selection:

■ All-in-One System
We’ve designed the control board with a microcontroller and external flash behind the TFT panel. It can drive TFT, backlight, and touch panel directly.

■ Convenient to Upgrade
The firmware can be updated online via a dongle to upload your latest version instead of using a physical programming machine.

■ Less Coding Process
The process of programming and testing can be done by our software app "Clever system user API". This tool can not only show the control data for coding instruction but also demonstrate what you want directly so that you can reduce the time on project development.

■ Reduce I/O Port
Customers can use the UART interface to drive the TFT directly. A suitable USB adapter is also included in the scope of supply.

TOP



Winstar released 3.5”and 4.3”Entry Level UART TFT.
Check the below links for details:

Model No.WL0F00035000LNFAAEA00 Model No.WL0F00043000UNFAAEA00 Model No.WL0F00043000UGFAAEA00

Model No.WL0F00035000LNFAAEA00

Model No.WL0F00043000UNFAAEA00

Model No.WL0F00043000UGFAAEA00

TOP



WF70C4SIAGDNG0: 7”High Brightness RGB TFT with PCAP


WF70C4SIAGDNG0 is a 7-inch High Brightness TFT LCD module with Projected Capacitive Touch Panel (PCAP), resolution WVGA 800x480 pixels. This TFT model is built-in with EK79713B and EK73202A ICs and supports 18-bit RGB interface. Please note that the WF70C4 series is an alternative solution for the WF70H series which has been End-of-Life (EOL). For more details, please get in touch with our sales persons.


Read more about WF70C4SIAGDNG0

Model No.WF70C4SIAGDNG0
TOP



Tech Article:How does the HOST switch page with SmartDisplay products - CANbus



When the system integrates and promotes SmartDisplay products, the focus is more on introducing its own features and functions, and less on how to operate SmartDisplay products from the perspective of client host control. We uses switching pages as an example to simulate how the client host issues command to display for switching pages.

winstar-Smart Display

Smart Display Solution Features


■ The user interfaces are well defined as objects.
■ Built in flash memory, store the font and Object Dictionary data.
■ Get started quickly, suitable for fast and easy integration of a HMI into any application.
■ Design the UI without writing a line of code by winstar GUI builder!

Read more about simulation introduction
